3. Cabling

3-16

TI 33J01J10-01EN

F030425.ai

Functional grounding terminal

(screw: M3)

System power supply

input connector

Field power supply input connector

A2BN3D-





Functional grounding terminal for cable shield

(screw: M3)

Functional grounding terminal

(screw: M3)

Cable

Shield

Dedicated cable

Connector

(A2KPB00)

Cable fixing screws

Connector (Base Plate Accessory)

Oct.5, 2018-00
