Table Signal Cables for Connection with FIO (3/3)
Module Name
I/O channels
per Module
Connection Signal
Pressure
Clamp
Terminal
Yokogawa-
specic
Cable (*1)
MIL
Cable
Analog I/O Modules with Built-in Barrier
ASI133 Analog Input Module (4 to 20 mA, Isolated) 8 x – –
ASI533 Analog Output Module (4 to 20 mA, Isolated) 8 x – –
AST143
-100 to 150 mV, -50 to 75 mV, Isolated)
16 x – –
ASR133
8 x – –
Digital I/O Modules with Built-in Barrier
ASD143 Digital Input Module (NAMUR compatible, Isolated) 16 x – –
ASD533 Digital Output Module (Isolated) 8 x – –
Turbomachinery I/O Modules
AGS813 12 – –
AGP813 High Speed Protection Module (Isolated) 26 – –
x : Can be connected.
– : Cannot be connected.
CAUTION
fold of the diameter of the cable.
Oct. 5, 2018-00
