YOKOGAWA CENTUM CS 3000 User Manual

3. Cabling
3-82
TI 33J01J10-01EN
lWhen receiving dry contact signals (Input frequency: 0 to 10 kHz)




connecting a shunt resistor unit between terminal-B and C of the external terminal block.

A2SAP105
SW1
4 kΩ
SW2
FIL
12 V DC/24 V DC
INA
INB
INC
IND
Transmitter
1.02 kΩ
F030708.ai
Direct field wiring to base plate
INC
IND
DIN rail
Signal Line
Shunt resistor unit
(A2EXR001)
Terminal block of A2BN3D
Shunt resistor module

A

B
510Ω
510Ω
INA
INB
: 1 to 16
F030726.ai
A2SAP105
Field wiring via terminal board
Dedicated cable
＋A2BM4
External
terminal block
SW1
4 kΩ
SW2
Input filter
12 V DC/24 V DC
INC
Transmiter
INA
1.02kΩ
INB
INC
INB
DIN rail
Signal Line
Shunt resistor unit
(A2EXR001)
External terminal block
Shunt resistor module

A

B
510Ω
510Ω
INA
: 1 to 16
Figure When receiving dry contact signals (Input frequency: 0 to 10 kHz)
