Table Maximum Power Consumption of FIO (2/2)
Model
name
Name
Max. Current
consumption
5 V DC (mA)
Max. current
consumption
24 V DC (mA)
Digital I/O Modules
ADV151 Digital Input Module (32-channel, 24 V DC) 500 –
ADV551 Digital Output Module (32-channel, 24 V DC) 700 –
ADV141 Digital Input Module (16-channel, 100 to 120 V AC) 500 –
ADV142 Digital Input Module (16-channel, 220 to 240 V AC) 500 –
ADV157
Digital Input Module
(32-channel, 24 V DC, Pressure Clamp Terminal Support Only)
350 –
ADV557
Digital Output Module
(32-channel, 24 V DC, Pressure Clamp Terminal Support Only)
550 –
ADV161 Digital Input Module (64-channel, 24 V DC) 550 –
ADV561 Digital Output Module (64-channel, 24 V DC) 780 –
ADR541 Relay Output Module (16-channel, 24 to 110 V DC/100 to 240 V AC) 780 –
ADV859
Digital I/O Module for Compatible ST2
(16-channel Input/16-channel Output, Isolated Channels)
450 –
ADV159
Digital Input Module for Compatible ST3
(32-channel Input, Isolated Channels)
330 –
ADV559
Digital Output Module for Compatible ST4
(32-channel Output, Isolated Channels)
570 –
ADV869
Digital I/O Module for Compatible ST5 (32-channel Input/32-channel
Output, Common Minus Side Every 16-channel)
800 –
ADV169
Digital Input Module for Compatible ST6
(64-channel Input, Common Minus Side Every 16-channel)
800 –
ADV569
Digital Output Module for Compatible ST7
(64-channel Output, Common Minus Side Every 16-channel)
800 –
Communication Modules
ALR111 RS-232C Communication Module (2-Port, 1200 bps to 115.2 kbps) 500 –
ALR121
RS-422/RS-485 Communication Module
(2-Port, 1200 bps to 115.2 kbps)
500 –
ALE111 Ethernet Communication Module (1-Port, 10 Mbps) 500 –
ALF111
Foundation Fieldbus (FF-H1) Communication Module
(4-Ports, 31.25 kbps)
500 –
ALP111 PROFIBUS-DP Communication Module 700 –
Analog I/O Modules with Built-in Barrier
ASI133 Analog Input Module (4 to 20 mA, 8-channel, Isolated) 150 450
ASI533 Analog Output Module (4 to 20 mA, 8-channel, Isolated) 150 350
AST143
TC/mV Input Module (TC: B, E, J, K, N, R, S, T / mV: -100 to 150 mV, -50
to 75 mV, 16-channel, Isolated)
150 80
ASR133
RTD/POT Input Module (RTD: Pt50, Pt100, Pt200, Pt500, Pt1000, Ni100,
Ni200, Ni120 / POT: 0 to 10 kΩ, 8-channel, Isolated)
150 60
Digital I/O Modules with Built-in Barrier
ASD143 Digital Input Module (16-channel, NAMUR compatible, Isolated) 150 110
ASD533 Digital Output Module (8-channel, Isolated) 150 500
