4. Installation Specifications
4-19
TI 33Q01J10-01E Feb. 1, 2009-00
ABC11S, ABC11D
Table Periodic Replacement Parts Having Defined Life Spans
Part names
Part
numbers
Recommended
Replacement Interval
Replacement
by user
Remarks
Air Filter T9070CK
1 year Yes Clean it every three months
Fun AIP601
4 years Yes
Battery Pack S9400UK
3 years Yes Average ambient temperature 30 °C or less
1.5 years Yes Average ambient temperature 40 °C or less
9 months Yes Average ambient temperature 50 °C or less
Aluminium
Electrolytic
Capacitor
(in power supply
unit)
(PW301) 8 years No
100 V AC
Average ambient temperature 40 °C or less
(PW302) 8 years No
220 V AC
Average ambient temperature 40 °C or less
(PW304) 8 years No
24 V DC
Average ambient temperature 40 °C or less
Built-in power fuse
S9052VK
3 years No 100-120 V AC, 250 V, 8 A, F
S9580VK
3 years No 220-240 V AC, 250 V, 6.3 A, F
S9504VK
3 years No 24 V DC, 250 V, 15 A, F
Paint Colors
Table Paint Colors
Painted section
Paint color
(Reference Munsell values in parentheses)
Major unit types
Basic color Frosty white (2.5Y8.4/1.2)
LPCKIT, YPCKIT, YAX801, AFS20S/AFS20D,
AFS40S/AFS40D, AFG20S/AFG20D, AFG40S/
AFG40D
Channel base Spring Black (3.3PB2.5/0.5)
LPH21C, YPCKIT, YAX801, AFS20S/AFS20D,
AFS40S/AFS40D, AFG20S/AFG20D, AFG40S/
AFG40D
