  4.InstallationSpecications
4-6
TI 33J01J10-01EN
Table Maximum Power Consumption of FIO (3/3)
Model name Name
Max. current
consumption
5 V DC (mA)
Max. current
consumption
24 V DC (mA)
Analog I/O Modules (for RIO System Upgrade)
AAB841
-K


– 330
AAI143
-M
Analog Input Module (4 to 20 mA, 16-channel, Isolated) – 600
AAI543
-M
Analog Output Module (4 to 20 mA, 16-channel, Isolated) – 680
AAV144
-K
-M
Analog Input Module (-10 to +10 V, 16-channel, Isolated) – 130
AAT145
-K
-M
Analog Input Module (-10 to +10 V, 16-channel, Isolated) – 130
AAR145
-K
-M

16-channel, Isolated Channels)
– 120
Digital I/O Modules (for RIO System Upgrade)
ADV159
-K
-M
Digital Input Module for Compatible ST3
(16-channel Input, Isolated Channels)
– 120
-Y
– 300
ADV559
-K
-M
Digital Output Module for Compatible ST4
(32-channel Output, Isolated Channels)
– 130
-Y
– 410
ADV169
-K
-M
Digital Input Module for Compatible ST6

– 170
ADV569
-K
-M
Digital Output Module for Compatible ST7

– 190
n Maximum Power Consumption of N-IO
Mode Name Max current cosumption 24 V DC (A)
A2BN3D  8 A
A2BN4D Base Plate for Barrier (Barrier Power Supply) 1.6 A
A2BN5D Base Plate for Barrier (Barrier Power Supply) 1.2 A
June 30, 2016-00
