YOKOGAWA CENTUM CS 3000 User Manual

2. Transportation, Storage and Installation
2-40
TI 33J01J10-01EN
Mar. 29, 2019-00
l ExampleofMountinganFCUforN-IOandN-IONodesinaCabinet(Foreld
wiring via terminal board)
Temperature conditions
In this example, the ambient temperature is assumed to be the followings.
Cabinet ambient temperature 40 °C or less
Maximum numbers of units that can be mounted in case of this example
Type Model Number of units that can be mounted per side
  Up to 1
NIU A2NN30D Up to 2
IOBP A2BN3D 

Mounting conditions
 
ceiling.
 
 
 
• Suitable length of signal cables and power cables should be used.
