3. Cabling
3-15
TI 33Q01J10-01E
AFS30S/AFS30D, AFG30S/AFG30D Field Control Unit (19-inch Rack
Mountable Type)
F030405.ai
L N
READY
TM1
TM1
Power supply
(Terminal screw: M4)
READY contacts
(Terminal screw: M4)
ESB bus coupler
(Refer to “Section 3.8 ESB Bus”)
REVISION
U H1 H2
MODEL
AIP532
STYLE1 SI
YOKOGAWA
ESB Bus
CN1
RCV
SND-L
SND-R
REVISION
U H1 H2
MODEL
AIP532
STYLE1 SI
YOKOGAWA
ESB Bus
CN1
RCV
SND-L
SND-R
REVISION
U H1 H2
MODEL
AIP532
STYLE1 SI
YOKOGAWA
ESB Bus
CN1
RCV
SND-L
SND-R
Figure AFS30S/AFS30D, AFG30S/AFG30D Cable Connections
IMPORTANT
If wiring the contact output cable to the READY contact output terminals, attach a clamp filter
(part No. A1193MN with cable fastener) supplied with AFS30S/AFS30D and AFG30S/AFG30D,
near the terminals.
This inside diameter of the core is 9±1 mm.
F030410.ai
READY
TM1
FUSE
RL1 RL2
FAN ALARM
N1 N2
Clamp Filter
Contact Output
Terminals
Contact Output Terminals (external interface unit)
Figure Clamp Filter
Nov. 20, 2003-00
