OCR Programming

251

OCR-B Variant (continued)

For the best performance in passport reading, fix the target passport and the decoder in place (6.5 - 7.5”).

NOTE: Enable OCR-B before setting this parameter. If disabling OCR-B, set the variant to its default

(OCR-B Full ASCII).

*OCR-B Full ASCII

(0)

OCR-B Banking

(1)

OCR-B Limited

(2)

OCR-B ISBN 10-Digit Book Numbers

(6)

OCR-B ISBN 10 or 13-Digit Book Numbers

(7)

OCR-B Travel Document Version 1 (TD1)

3 Line ID Cards

(3)
