OCR Programming

252

OCR-B Variant (continued)

OCR-B Travel Document Version 2 (TD2)

2-Line ID Cards

(8)

Travel Document 2 or 3-Line ID Cards Auto-Detect

(20)

OCR-B Passport

(4)

OCR-B Visa Type A

(9)

OCR-B Visa Type B

(10)

OCR-B ICAO Travel Documents

(11)
