6166 DC Voltage Current Source Operation Manual
3.8.7 Starting, Stopping and Pausing Memory Scan
3-52
(2) This is an example to execute Single scan.
Operating procedure
Check that the source value screen is displayed.
If the menu screen, limit setting screen or numeric keypad input screen is displayed, press the EXIT
key.
If the program function has been already enabled, go on to Step .
Press . The program function is enabled and the program screen is displayed.
While the program screen is displayed, the PROGRAM key lights up.
Press to select Single scan.
The upper left display switches as Hld  Sng  Rpt.
Display example Program screen
Press to output the source value. The source value of memory number 0 is output.
While the source value is output, the OPERATE key lights up.
4152 6
7
38
1
3
2
3
Shows that the scan operation is set to Single.
4
