6166 DC Voltage Current Source Operation Manual
8.3.2 Manual Calibration Procedures
8-19
After waiting for five or more seconds, input the converted current value by using the rotary knob or
numeric keypad.
Converted current value (A) = DMM measured voltage (V) / Standard resistance for calibration ()
Press to confirm the input and return to the original screen.
The 1 mA range output has been adjusted by the above steps.
Next, whether it has been correctly adjusted or not is checked.
Press to switch the calibration target to zero point.
Check that the digital multimeter read value meets the tolerance range (See Table 8-2).
Press to switch the calibration target to + full scale
Check that the digital multimeter read value meets the tolerance range (See Table 8-2).
Press to switch the calibration target to - full scale.
Check that the digital multimeter read value meets the tolerance range (See Table 8-2).
If any result is out of the tolerance range, repeat the above procedure to perform calibration on all the
calibration targets.
Press to set the output to OFF.
When calibrating another range, repeat the above procedure from Step .
NOTE: The calibration must include zero point calibration, + full scale calibration and - full scale calibration.
