6166 DC Voltage Current Source Operation Manual
9. SPECIFICATIONS
9-3
Source linearity:
At temperature of 23C10C, relative humidity of 70 % or less and constant power and load
For the current ranges, with a compliance voltage of 10 V or less
Thermal electromotive force source range: The thermal electromotive force source is divided output.
Reference junction temperature (cold junction compensation) setting range:
-270 C to +120 C except for the following:
Thermocouple type J: Less than -210C is deemed to be -210C.
Thermocouple type S: Less than -50C is deemed to be -50C.
Thermocouple type R: Less than -50C is deemed to be -50C.
Thermocouple type B: Less than 0C is deemed to be 0C.
Standard setting: JIS C1602-1995 or JIS C1602-1981
For type N, JIS C1602-1995 is applied.
Range Linearity
10 mV 0.03 V
100 mV 0.3 V
1000 mV 4 V
1 V 3 V
10 V 30 V
100 V 400 V
1000 V 5 mV
1 mA 3 nA
10 mA 30 nA
100 mA 500 nA
Thermocouple Source range Setting resolution
T (CC) -220.0C to +400.0 C0.1 C
J (IC) -210.0C to +1200.0 C0.1 C
E (CRC) -220.0
C to +1000.0 C0.1 C
K (CA) -220.0C to +1372.0 C0.1 C
S (PR10) -10.0C to +1768.0 C0.1 C
R (PR13) -10.0C to +1768.0C0.1 C
B (PR30) +280.0 C to +1820.0C0.1 C
N -220.0C to +1300.0 C0.1 C
