6166 DC Voltage Current Source Operation Manual
9. SPECIFICATIONS
9-7
Voltage/current limiter:
Source Function
Program function: Recall Specifies an arbitrary memory number.
Scan Scans memory numbers one by one by trigger input.
Increments memory numbers at intervals specified by the
step time.
Scan operation Hold Scans memory numbers one by one by trigger
input.
Single Scans from the first number to the last number.
Repeat Scans repeatedly from the first number to the last
number.
Maximum memory 1000 data
Step time Setting range 1 s to 99 s
Setting resolution 1 s
Accuracy: Within 5 % of setting time
Time to change the function or range is added to the step
time.
Limiter: Current limiter
Voltage limiter
Output system: Floating, bipolar
Output terminal: Front/rear, biding post
+OUTPUT, +SENSE, -OUTPUT, -SENSE, DIVIDED OUT-
PUT HI, DIVIDED OUTPUT LO, GUARD, GND
Maximum input between:
(*6) For information on external voltage application, refer to Section 5.2,
"Source and Sink Operations."
OUTPUT and SENSE 0.5 V peak max
DIVIDED OUTPUT HI and LO 2 V peak max
Setting range Resolution Setting accuracy
Voltage limiter 10 V to 1250 V 1 V 3 % of setting 5 V (*5)
Current limiter 1 mA to 125 m A 1 mA 3 % of setting 0.8 mA
*Available except for the divider voltage ranges (10 mV, 100 mV and 1000 mV)
(*5): 1 V is added for current source.
+OUTPUT
+SENSE
and
-OUTPUT
-SENSE
1200 V output max (*6)
-OUTPUT
-SENSE
DIVIDED OUTPUT LO
and GUARD 50 V peak max
