6166 DC Voltage Current Source Operation Manual
9. SPECIFICATIONS
9-6
Settling time: Time to settle to the final value 0.001 % when varying from zero to the full scale
(For the 100 mA range, time to settle to the final value 0.0015 %)
For the OPT6166+20, time to settle to the final value 0.005 % in the 1 mA and 10 mA ranges is within 5
sec (at load of 1 M or less and 100 k or less respectively).
Line regulation: 0.0003 % of range or less for 100 VAC change of 10 %
Maximum load capacitance: Maximum value that does not oscillate in voltage source
Maximum load inductance: Maximum value that does not oscillate in current source
Current source: 1 mH
CMRR: Voltage output
DC 140 dB or more
50/60 Hz 1 % 80 dB or more
Current output
DC 140 dB or more
50/60 Hz 1 % 80 dB or more
At unbalanced impedance of 1 kW between the -OUTPUT/-SENSE terminal
and the GUARD terminal
Range Settling time Load condition
Voltage source
10 mV
1 sec or less
-
100 mV
1000 mV
1 V
10 V
100 V
1000 V 10 sec or less (*4)
Current source
1 mA
1 sec or less
100 k or less
10 mA 10 k or less
100 mA 1 k or less
(*4): Time to settle to the final value 0.05 % in the 1000 V range is within 3 sec.
Range Maximum load capacitance
10 m V to 10 V 1000 F
100 V 10 F
1000 V 1 F
