6166 DC Voltage Current Source Operation Manual
9. SPECIFICATIONS
9-5
Load regulation/output resistance: In 2-wrie connection
Output noise: Within the range from no load to maximum load for voltage source
At load resistance of 1 k for current source
Range
Load regulation
(Load condition)
Output resistance Maximum output
Voltage source
10 mV
-
180 0.5 %
-100 mV 198 0.5 %
1000 mV 200 0.5 %
1 V 0.0008 % (10  or higher) 100 m or less
Output current
120 mA
10 V 0.0002 % (100  or higher) 100 m or less
100 V 0.0002 % (1 k or higher) 100 m or less
1000 V 0.0002 % (100 k or higher) 100 m or less Output current
12 mA
Current source
1 mA 0.0002 % (10 k or less) 5 G or higher (*1)
Output compliance
voltage 120 V (*2)
10 mA 0.0002 % (1 k or less) 5 G or higher (*1)
100 mA 0.0002 % (100  or less) 1 G or higher
(*1): 1 G or higher when the compliance voltage exceeds 120 V.
(*2): Up to 1200 V for the 1 mA and 10 mA ranges of the OPT6166+20.
Range
Low frequency noise High frequency noise
0.1 Hz to 10 Hz (rms) 10 Hz to 10 kHz (rms) DC to 20 MHz (p-p)
Voltage source
10 mV 0.2 V20 V1 mV
100 mV 0.5 V20 V1 mV
1000 mV 1 V20 V1 mV
1 V 2 V 100 V3 mV
10 V 10 V 100 V3 mV
100 V 100 V 100 V3 mV
1000 V 1 mV 1 mV 10 mV
Current source
1 mA 5 nA 50 nA 2 A (10 A) (*3)
10 mA 20 nA 200 nA 2 A (10 A) (*3)
100 mA 200 nA 500 nA 10 A
(*3): The values is parentheses are for the 1 mA and 10 mA ranges of the OPT6166+20.
