Chapter 5 Connecting Customer-Supplied Safety and Power Control Equipment to the CIP
108 Adept MV Controller User’s Guide, Rev. B
The CIP includes support for turning on and off system power to the controller. If
you use this switch, you must provide an AC contactor with the following
electrical characteristics:
• 12V or 24V, AC or DC coil, limited to less than 500 mA
The user connection for system power is at the JUSER connector (pins 6 and 24).
You will need to provide a power supply to match the coil voltage of the external
contactor.
In addition, the system power switch has a second pole that is wired through the
25-pin cable to the Manual Mode Safety Package. Access to this pole is at TB5,
pins 5 and 6, on the E-Stop PCA of the MMSP. You can wire to whichever contact
is more convenient.
Manual Mode Safety Package (MMSP) Connector
The CIP also provides a connection for a user supplied MMSP circuit (see '
(, '(, 94% ( , and 94%( for the customer MMSP circuitry).
Remote User Panel Connections
The CIP provides connections for a remote user panel circuitry that allows a
second user panel at another location (see '(, '(, 9 4% (, and
94 % ( for the customer remote user panel circuitry).
Remote MCP Connections
For the following remote MCP connections see '(, and '(, and
refer to 94%( and 94% ( for the customer Remote MCP circuitry.
If a remote MCP connection has been added through the
JUSER connector, the optional MCP bypass plug (P/N 10335-01060)
must be installed in the MCP connector on the CIP.
Remote E-Stop Circuit
When using a remote connector for the MCP, the MCP E-stop push button
contacts (red mushroom switch) must be wired in series with any other E-stop
contacts on the “USERESTOP CH1”(pins 4 and 23) and “USERESTOP CH1” (pins
5 and 24).
