Chapter 7 Installing Camera Cables

Adept MV Controller User’s Guide, Rev. B 151

Installing Camera Cables

See the AdeptVision User’s Guide for information on mounting cameras and

strobes in your system. Figure 7-7 shows the installation of a typical four-camera

RS-170 breakout cable and the associated hardware.

CAUTION:

Turn off the controller before installing or removing a

camera or cable. Failure to do this may damage the EVI board.

Connecting the Cables to the RS-170 Standard Camera

This section describes the steps for connecting the cables between the EVI board

and the RS-170 Cameras.

1. Turn off the Adept MV controller.

2. Connect the camera to a 10m camera cable.

3. Connect the 10m camera cable to the appropriate connection on the camera

breakout cable.

4. Connect the power supply and strobe lamps through the 9 pin D-sub

connector (see Table 7-7 for pin assignments).

5. Connect the camera breakout cable to the camera/strobe connection on the

EVI board.
