Chapter 4 Configuring an AWC Module
Adept MV Controller User’s Guide, Rev. B 79
DIP-Switch Settings
The following table shows the options for DIP switch SW1 on the AWC module.
The AWC processor must be removed from the controller to set this DIP switch.
See '( for the location of DIP switch SW1.
Table 4-3. SW1 Settings
SW 4 SW 3 SW 2 SW 1 Interpretation
ON ON ON ON CPU #1, no auto boot, all other settings per
/9-.
ON ON ON OFF CPU #1, no auto boot, user interface via VGB or serial
port (use serial port if VGB is absent, or if a VGB is
present but its use is disabled with its DIP switch #4)
ON ON OFF ON CPU #1, no auto boot, user interface via serial port
ON ON OFF OFF CPU #1, no auto boot, user interface via serial
AdeptWindows
ON OFF ON ON CPU #1, no auto boot, user interface via Ethernet
AdeptWindows (use IP address in
/9-.
)
ON OFF ON OFF CPU #1, no auto boot, user interface via Ethernet
AdeptWindows (use default IP address)
ON OFF OFF ON Reserved for future use
ON OFF OFF OFF Reserved for future use
OFF ON ON ON Reserved for future use
OFF ON ON OFF Reserved for future use
OFF ON OFF ON CPU #1, no auto boot, use SIO switches to select I/O
OFF ON OFF OFF CPU #1, auto boot, use SIO switches to select I/O
OFF OFF ON ON Reserved for future use
OFF OFF ON OFF Reserved for future use
OFF OFF OFF ON CPU #2
OFF OFF OFF OFF CPU #1, normal operation (per
/9-.
settings)
