Chapter 6 Monitor Video Interface
Adept MV Controller User’s Guide, Rev. B 135
Monitor Video Interface
The VGB board supports a color monitor with a resolution of 1024 by 768. See
Table 6-3 for the monitor compatibility specifications. The pin assignments for the
Monitor connector are shown in Table 6-2.
Table 6-2. Monitor Connector Pin Assignments
Pin Signal Pin Signal
1 Red Video Output 9 Not connected
2 Green Video Output 10 Ground
3 Blue Video Output 11 Ground
4 Ground 12 Not connected
5 Self Test (Ground) 13 Horizontal Sync
6 Red Video Ground 14 Vertical Sync
7 Green Video Ground 15 Not connected
8 Blue Video Ground
Table 6-3. Monitor Compatibility Specifications
Video Display Resolution 1024 x 768 pixels
Frame Rate 60 Hz
Format Noninterlaced
Line Rate 48.363 kHz
Dot Rate 65.000 MHz
Video signal Analog RGB
Signal level 0 - 0.7 Vp-p
Input Impedance 75 ohm ±5% at 100 kHz
