Chapter 7 Camera Compatibility
Adept MV Controller User’s Guide, Rev. B 145
Camera Compatibility
Standard RS-170 Cameras
Compatible cameras can be purchased from Adept. See the AdeptVision User’s
Guide for a list of other cameras that can be used with the AdeptVision product. If
you have a camera that is not on that list, the following information presents some
guidelines for camera compatibility with AdeptVision (minimum requirements):
• RS-170 camera video output (US-style monochrome, 30Hz frame rate [60Hz
field rate], 525 lines, interlaced)
• External Hd and Vd sync signals (inputs to camera)
1
• Connector: Hirose HR10-10S-12P
• Pinout: typical Sony/Panasonic, etc. (See Table 7-7 for pinout)—not Pulnix
standard pinout (Pulnix cameras maybe special ordered with Sony pinouts).
Use these guidelines to determine camera compatibility. If the camera meets the
above requirements, there is a good chance that it will work as a plug and play
device.
The pixel resolution of the Adept frame store is 1Kx1K and will work with
cameras with a resolution of 500 x 480 or greater. If the camera, lens, etc., are good
quality, the actual number of pixels does not affect compatibility, because the
interface uses the RS-170-standard analog video-link.
High-Resolution Cameras
The only qualified 1024 x1024 pixel camera is the Pulnix TM-1001. This camera
must be ordered from Pulnix with “option 24-2” to correctly configure the
pinouts. A maximum of two TM-1001 cameras may be connected to the EVI
board. For more details see the AdeptVision User’s Guide
1
For interfacing cameras without external sync, contact Adept Application Support; see
“How
Can I Get Help?” on page 34
.
