Chapter 3 Installing a Monitor and Keyboard
64 Adept MV Controller User’s Guide, Rev. B
Installing a Monitor and Keyboard
The peripheral equipment such as the keyboard and monitor
supplied by Adept are intended for use in light industrial
conditions. In more severe conditions, they should be protected
with a suitable enclosure.
Installation Procedure
An Adept controller can be configured with a color monitor and an extended
keyboard with built-in trackball. Both of these devices can connect to the optional
VGB board. See the
for details on using the
keyboard and trackball.
See Figure 3-6 for details; the steps are listed below.
1. Make sure the controller is turned off before making any connections.
2. Verify that the voltage range marked on the monitor is compatible with your
local voltage source. Connect the color monitor AC power cord to the monitor,
then plug it into an appropriate voltage source.
3. Connect the monitor signal cable to the
.*/*-
connector on the VGB board.
4. Connect the double-ended keyboard cable to the
4,5*-6
connector and
the
%*/,-
connector on the VGB board.
