Chapter 3 Controller ID Label
50 Adept MV Controller User’s Guide, Rev. B
Controller ID Label
On the MV-5 and MV-10 controllers, the identification (ID) label is located on the
left or back side of the controller chassis. On it you will find the model and serial
numbers and the voltage and current ratings. A smaller serial number label is also
located on the front of the chassis near the On/Off switch (see Figure 3-1). You
should always have this serial number available when you call Adept Customer
Service for technical support.
See “Adept MV-4 Insert Overview” on page 57 for the location of the ID label on
the Compact Controller.
Facility Requirements
The Adept controller is intended for use with other equipment and is considered
a subassembly rather than a complete piece of equipment on its own. The Adept
controller meets the requirements of EN 60204-1, EN 61131-2,
IEC 204, IEC 1131-2, IEC 73, and IEC 447 safety standards. To maintain
compliance with these standards, the controller must be installed and used
properly with any additional equipment in strict accordance with these
standards. For more information about safety and standards compliance, see
“Safety” on page 30, “Standards Compliance” on page 33, and Appendix C.
The Adept controller installation must meet the environmental and electrical
requirements shown in Table 3-1 and Table 3-2.
Table 3-1. Operating Environment Specifications
Environment Variable Specification
Ambient temperature
controller – while accessing floppy
or hard drive
controller – while not accessing
floppy or hard drive
5°C to 40°C (41 to 104°F)
5°C to 50°C (41 to 122°F)
Humidity 5 to 90%, noncondensing
Altitude up to 2000 m (6500 ft.)
Pollution degree 2 (per IEC 1131-2/EN 61131-2)
