Chapter 4 AWC Board
Adept MV Controller User’s Guide, Rev. B 77
AWC Board Specifications
Table 4-1. AWC Board Specifications
Processor 68040 @ 25MHz or 68060 @ 50MHz
Dynamic RAM 8 or 24 Mb (subject to change)
Serial Ports Three RS-232, at 300-38,400 bps
One RS 422/485 at 300-38,400 bps
Ethernet 10 base T (100 base T will be available in future)
Compact Flash (mass
storage)
8 or 30 Mb
Electrical Power
Consumption
5V @ 4A, 12V @ 1 A, –12V @ 0.5 A, 24V @ 0.5 A
Environmental Temperature: Operating 0° C to + 55° C, cooling air exit
Nonoperating –40° C to + 85° C
Humidity: Operating 10%-80% Nonoperating
10%-90%
System I/O DeviceNet with CANbus interface
Four Fast Inputs @ 0-24VDC, 5mA
Auxiliary I/O Via I
2
C
12 digital inputs and 8 outputs
32 digital inputs and outputs (JSIO connectors on CIP)
Width Occupies one VME backplane slot
