Chapter 13 Changing the Lamp on the High Power Indicator
Adept MV Controller User’s Guide, Rev. B 213
Changing the Lamp on the High Power Indicator
The system is equipped with circuitry to detect the potentially dangerous
condition of a burned out High Power indicator. If this lamp is burned out, you
cannot enable High Power until the lamp has been replaced. To replace the High
Power indicator bulb:
1. Turn off the controller and disconnect system power.
2. Remove all cables from the back and side of the CIP.
Make sure that the cables connected to JDIO1 through
JDIO4 are properly labeled. The two input cables can be swapped
and the two output cables can be swapped. This could result in a
dangerous situation when you restart the controller.
3. Remove the CIP from its mounting location.
4. Remove the six screws from the front of the CIP as shown in '(. Also
remove the MCP bypass plug retaining screw.
