Chapter 12 DIO Board Specifications
Adept MV Controller, User’s Guide, Rev. B 207
DIO Board Specifications
Table 12-9. DIO Board Technical Specifications
a
a
Specifications subject to change.
Electrical Power Consumption 5 VDC 1.0 A typical
5 VDC 1.2 A max
+12 VDC none
–12 VDC none
Width Occupies one backplane slot
Inputs (see Table 12-1 for input circuit specifications)
Number of channels 32 (4 groups of 8)
Isolation — any I/O group to any
I/O group
— any I/O group to
VME bus
300 VDC
1000 VDC
Outputs (see Table 12-3 for output circuit specifications)
Number of channels 32 (4 groups of 8)
Output configuration Current sourcing outputs
Power supply voltage 10 to 15 or 15 to 30 VDC, jumper
selectable
Output transient protection Reverse voltage protection and transient
suppression provided.
