Chapter 3 Installing the MV-5 and MV-10 Controllers
Adept MV Controller User’s Guide, Rev. B 55
Connecting AC Power Cord
The AC power cord is included in the accessory kit. The controller end of the
power cord is fitted with an IEC 320 connector. The user end of the cord is not
terminated. Connect each conductor of the power cord securely to your AC
power source, using the color code below. You must provide a suitable plug or
other facility connection in accordance with all applicable local and national
codes. See the next section for important information on system grounding.
System Grounding Information
The detachable three-wire power cord is used for connection to both the power
source and protective ground. The protective ground conductor (colored
green/yellow) in the power cord is internally connected to the exposed metal
parts of the MV Controller. To ensure electrical-shock protection, the protective
ground conductor must be connected to a properly grounded power source.
Ensure that a proper protective ground connection exists
before turning on the power.
Fuse Information (MV-5 and MV-10)
The two fuses (F1 and F2) at the power entry module on the front panel are for the
incoming AC power lines. See the table below for ratings.
Only skilled or instructed personnel should attempt to
change any fuses. Always replace blown fuses with new fuses of the
same type and rating.
Table 3-3. Power Cord Specifications
Cord length 3 meters ±0.1 m (9 ft. 10 in. ±4 in.)
Cord rating 10 amps
Number and size of
conductors
3 x 1.00 mm
2
Color code
line
neutral
ground
brown
blue
green/yellow
