SIO Board Specifications
Table 8-2. Technical Specifications
a
a
Specifications subject to change.
Electrical Power
Consumption (Supplied from
VME backplane)
System I/O (SIO) 5 V at 4.6 A typical
+12 V at 1.4 A
–12 V at 50 mA
Floppy Drive 5 V at 0.23 A average (0.74 A max)
12 V not used
Hard Drive 5 V at 0.6 A average (1.1 A max)
12 V not used
Width Occupies 2 backplane slots
Serial Ports Three RS-232, at 300 – 38.4K bps
