Appendix A Adept MV-5 and MV-10 Stand-Alone Controller Dimensions

218 Adept MV Controller User’s Guide, Rev. B

Adept MV-5 and MV-10 Stand-Alone Controller Dimensions

Figure A-1. Adept MV-5/10 Stand-Alone Outline Drawing

480.1 mm

420.3 mm

462.9 mm

420.3 mm

215.9 mm

158.8 mm

286.7 mm

15.0 mm

16.0 mm

8.7 mm

Note 1: Allow 75 mm minimum at front

for power cord and signal cable

clearance.

Note 2: Allow 25 mm minimum at right and

left sides for air intake and exhaust.

Note 1: Allow 75 mm minimum at

front for power cord and signal cord

clearance

Note 1: Allow 25 mm minimum at right

and left sides for air intake and exhaust
