adept technology MV User Manual

Chapter 5 Connecting User-Supplied Digital I/O Equipment
116 Adept MV Controller User’s Guide, Rev. B
Digital I/O Connector Ordering Details (Third-Party Sources)
The JSIO connector on the CIP is a 50-pin, D sub-miniature Female socket. The
user-supplied cable must terminate in a suitable 50-pin Male D-sub plug. (The
plug is not supplied by Adept.)
Compatible connectors are manufactured by AMP and by Thomas and Betts.
Contact your nearest AMP or T&B Sales Office to locate your local distributor.
Table 5-7. JSIO Digital I/O Connector Pin Assignments
Pin
Signal
Name Pin Signal Pin Signal Pin Signal
1 Input 1001 2 1001 return 27 Output 0002+ 28 Output 0002–
3 Input 1002 4 1002 return 29 Output 0003+ 30 Output 0003–
5 Input 1003 6 1003 return 31 Output 0004+ 32 Output 0004–
7 Input 1004 8 1004 return 33 Output 0005+ 34 Output 0005–
9 Input 1005 10 1005 return 35 Output 0006+ 36 Output 0006–
11 Input 1006 12 1006 return 37 Output 0007+ 38 Output 0007–
13 Input 1007 14 1007 return 39 Output 0008+ 40 Output 0008–
15 Input 1008 16 1008 return 41
a
a
Pins 41, 42, 43, and 44: See
'(0
and
94%(
for more information.
Auxiliary
E-Stop input+
42
a
External
E-Stop input–
17 Input 1009 18 1009 return 43
a
Auxiliary
E-Stop input –
44
a
External
E-Stop input
+
19 Input 1010 20 1010 return 45 Passive
E-Stop
output+
46 Passive
E-Stop
output–
21 Input 1011 22 1011 return 47 Not used 48 Not used
23 Input 1012 24 1012 return 49 Not used 50 Not used
25 Output
0001+
26 Output
0001–
See next section for information on ordering a compatible third-party connector.
