Appendix A Compact Interface Panel Dimensions
222 Adept MV Controller User’s Guide, Rev. B
Compact Interface Panel Dimensions
Figure A-5. CIP Dimensions
16 INPUTS
GROUP 1,2 (JDIO1)
16 INPUTS
GROUP 3,4 (JDIO2)
16 OUTPUTS
GROUP 1,2 (JDIO3)
16 OUTPUTS
GROUP 3,4 (JDIO4)
DEVICENET
(JDVC)
I/O 12 IN, 8 OUT,
AUX ESTOP (JSIO)
AUX (JEXT) RS232 #4 (JCOM)
MMSP (JMMSP) CIB (JSLV)
AWC (JAWC) 50
USER (JUSER) 37
67.56 mm
(2.66 in)
279.10 mm
(10.99 in)
274.32 mm
12.70 mm
12.70 mm
106.68 mm
119.38 mm
(4.70 in)
132.08 mm
(5.20 in)
6.35 mm
(.25 in)
7.62 mm
(.30 in)
149.86 mm
(5.90 in)
304.80 mm
(12.00 in)
289.56 mm
(11.40 in)
71.58 mm
(2.82 in)
78.23 mm
(3.08 in)
(10.80 in)
(.50 in)
(.50 in)
(4.20 in)
250mm/s 100%
STOP
MCP
®
NET
