Chapter 7 Installing Camera Cables
Adept MV Controller User’s Guide, Rev. B 153
2. Connect the 10-meter camera extension cable to breakout connector cam1 and
the other end of the extension cable to the Hirose connector on the back of the
Pulnix camera.
3. Connect the BNC adapter cable to the auxiliary connector on the 4-camera
cable.
4. Connect the power and ground on the BNC adapter cable to a 12V power
supply that provides at least 600mA at 12V.
5. Each Pulnix TM-1001 camera requires 600mA at 12V. Therefore, if you are
using two Pulnix TM-1001 cameras, your power supply must be capable of
providing 600mA at 12V for each camera.
6. Connect Frame Reset 1 on the BNC adapter cable to the BNC connector on the
back of the first Pulnix camera.
7. Connect Strobe 1 on the BNC adapter cable to the first strobe light (optional).
To connect a second Pulnix TM-1001 camera:
1. Connect the 10-meter camera extension cable to breakout connector cam2 and
the other end of the extension cable to the Hirose connector on the back of the
Pulnix camera.
2. Connect Frame Reset 2 on the BNC adapter cable to the BNC connector on the
back of the second Pulnix camera.
3. Connect Strobe 2 on the BNC adapter cable to the second strobe light
(optional).
CAUTION: A maximum of two Pulnix TM-1001 cameras may be
installed on the EVI board.
NOTE: Do not mix Pulnix TM-1001 and RS-170 cameras on the same
EVI Vision board. They require different board switch settings. See
page 144
.
