Appendix G DeviceNet Physical Layer and Media
Adept MV Controller User’s Guide, Rev. B 385
Figure G-2. DeviceNet Thick Cable
Figure G-3. DeviceNet Thin Cable
Table G-3. DeviceNet Data Rates Relative to Cable Type and Length
Data Rates 125 Kbps 250 Kbps 500 Kbps
#  7 % 
@* 58A
?% 
@+? 58A
 
@?+ 58A
#  7  
@?+ 58A
 
@?+ 58A
 
@?+ 58A
1# ") 7 * 
@? 58A
*
@? 58A
*
@? 58A
&'#$ ") 7 %* 
@%? 58A
C+ 
@?%* 58A
 
@?+ 58A
11mm (0.43) Outside Diameter
65% Coverage Tinned
Copper Braid Shield
Polypropylene Fillers
Blue & White Data-Pair Polyethylene (18
AWG 19 x 30 Tinned & Stranded Copper
Conductors)
Red & Black DC Power Pair PVC (15 AWG
19 x 28 Tinned & Stranded Copper
Conductors)
18 AWG 19 x 30 Tinned
Copper-Stranded Drain Wire
Aluminum/Mylar Shield Over Each Pair
External Jacket
7.2mm (0.285 in) Outside Diameter
65% Coverage Tinned
Copper Braid Shield
Polypropylene Fillers
Blue & White Data-Pair Polyethylene (18
AWG 19 x 30 Tinned & Stranded Copper
Conductors)
Red & Black DC Power Pair PVC (15 AWG
19 x 28 Tinned & Stranded Copper
Conductors)
18 AWG 19 x 30 Tinned
Copper-Stranded Drain Wire
Aluminum/Mylar Shield Over Each Pair
External Jacket
Overall Non-Hydroscopic Wrap
