Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 149

Connect to Different EtherNet/IP Network Levels Chapter 6

6. If the following warning appears, read it carefully and click Yes

to continue.

IMPORTANT Before you change the EtherNet/IP mode, make sure that you

understand the impact of a mode change on your controller.

For more information on the impact of changing the EtherNet/IP

mode, see

Table 8 on page 144.
