156 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019

Chapter 6 Connect to Different EtherNet/IP Network Levels

Table 10 shows differences in RSLinx Classic software when the controller uses

Dual-IP mode or Linear/DLR mode.

Table 10 - EtherNet/IP Mode Display Differences in the RSLinx Classic Software

EtherNet/IP Mode

Section in

Software

Dual-IP Mode Linear/DLR Mode

General Tab

Port Configuration

Tab

Main Page
