162 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019
Chapter 7 Use I/O Modules
The New Module dialog box appears.
3. Configure the module and click OK.
To add additional local I/O modules, complete one of the following:
• If you cleared the Close on Create checkbox when you created the first
I/O module, repeat steps
2…3.
• If you did not clear the Close on Create checkbox when you created the
first I/O module, repeat steps
1…3.
For more information on how to use local I/O modules in a
CompactLogix 5480 system, see the resources that are listed in
Additional
Resources on page 10.
TIP Remember, if the Series and Revision parameter values do not match the
values of the module for which this configuration is intended, your project
can experience module faults.
