Chapter 10 Commercial Operating System
To use the reset button with the COS, complete the following steps.
1. If you want the controller to enter Operating System Utilities mode,
make sure that the mode switch is in the PROG position.
For more information, see
Table 18 on page 219
2. Use a small tool with a diameter of a paper clip to press and hold the
reset button.
3. Release the button when necessary, see the times that are listed in
Table 18 on page 219, to execute the desired task.
™
NET B1
LINK B1
NET A1
LINK A1
NET A2
LINK A2
SPEED X1
LINK X1
OK
RUN
FORCE
FAN 1
SD
FAN 2
CompactLogix 5480
B1
A1
1
2
A2
5069-L46ERMW
CONTROLLER
UPS
MP
SA
R
B
F
RUN
REM
PROG
RUN
REM
PROG
