Allen-Bradley CompactLogix 5480

282 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019
Appendix A Status Indicators
#0109 Invalid Connection Size
#0110 Module Not Configured
#0111 RPI Out of Range
#0113 Out of Connections
#0114 Wrong Module
#0115 Wrong Device Type
#0116 Wrong Revision
#0117 Invalid Connection Point
#0118 Invalid Configuration Format
#0119 Module Not Owned
#011A Out of Connection Resources
#0203 Connection Timeout
#0204 Unconnected Message Timeout
#0205 Invalid Parameter
#0206 Message Too Large
#0301 No Buffer Memory
#0302 Bandwidth Not Available
#0303 No Bridge Available
#0305 Signature Mismatch
#0306 CCM Not Available
#0311 Invalid Port
#0312 Invalid Link Address
#0315 Invalid Segment Type
#0317 Connection Not Scheduled
#0318 Invalid Link Address
#0319 No Secondary Resources Available
#031E No Available Resources
#031F No Available Resources
#0800 Network Link Offline
#0801 Incompatible Multicast RPI
#0814 Data Type Mismatch
#FD01 Bad Backplane EEPROM
#FD02 No Error Code
#FD03 Missing Required Connection
#FD04 No CST Master
#FD05 Axis or GRP Not Assigned
#FD0A Axis Attribute Reject
#FD1F Safety I/O
#FD20 No Safety Task
#FE01 Invalid Connection Type
Table 34 - I/O Fault Messages (Continued)
Code Message
