Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 57

Connect to the Controller Chapter 2

The New Entry dialog box appears.

4. Type an IP address, Hostname, and Description for the module.

Hostname and Description are optional.

5. Click OK.

IMPORTANT If your controller is operating in Dual-IP mode, you must set an IP address for

each controller Ethernet port. In this case, set the IP address for the other

ports by repeating

step 3…step 5 for each port.
