Amadas 9960 - Error Codes

9960 Self-Propelled Peanut Combine Monitors
MAN091 06/03/05 91
Error Codes
If any errors occur during the calibration
procedures, error codes display on the
tachometer.
• ER02 No header connected or invalid header
type.
• ER03 No corn head connected during deck plate
calibration.
• ER21 CONTOURMASTER™ angle sensor
voltage less than 0.5VDC.
• ER22 CONTOURMASTER™ angle sensor
voltage greater than 4.5VDC.
• ER23 CONTOURMASTER™ angle sensor
voltage noisy or changing in an incorrect
direction.
• ER24 CONTOURMASTER™ angle voltage
range less than 2.0VDC.
• ER25 CONTOURMASTER™ angle sensor “left”
voltage greater than 2.5VDC.
• ER26 CONTOURMASTER™ angle sensor “right”
voltage less than 2.5VDC.
• ER27 CONTOURMASTER™ angle sensor
center voltage is not within 0.75VDC of mid-
range.
• ER41 Deck plate position sensor voltage less
than 0.5VDC.
• ER42 Deck plate position sensor voltage greater
than 4.5VDC.
• ER43 Deck plate position sensor voltage noisy or
changing in an incorrect direction.
• ER44 Deck plate position sensor voltage noisy or
changing in an incorrect direction.
• ER45 Deck plate position sensor ”closed” voltage
greater than 2.5VDC.
• ER46 Deck plate position sensor “opened”
voltage less than 2.5VDC.
• ER51 Header height resume sensor voltage less
than 0.5VDC.
• ER52 Header height resume sensor voltage
greater than 4.5VDC.
• ER53.Header height resume sensor voltage
noisy or changing in an incorrect direction.
• ER54 Header height resume sensor voltage
range less than 2.0VDC.
• ER55 Header height resume sensor “lowered”
voltage greater than 2.5VDC.
• ER56 Header height resume sensor “raised”
voltage less than 2.5VDC.
• ER59 Header height resume sensor has
excessive hysteresis.
• ER71 Left height sensor voltage less than
0.5VDC.
• ER72 Left height position sensor voltage greater
than 4.5 VDC.
• ER73 Left height position sensor voltage noisy or
changing in an incorrect position.
• ER74 Left height position sensor voltage range
less than 2.0VDC (1.5 VDC for flex platforms).
• ER75 Left height position sensor “lowered”
voltage greater than 2.5VDC.
• ER76 Left height position sensor “raised” voltage
less than 2.5VDC.
• ER77 Left and right height sensor not stopping at
same feeder house position.
• ER81 Right height sensor voltage less than
0.5VDC.
• ER82 Right height position sensor voltage
greater than 4.5VDC.
• ER83 Right height position sensor voltage noisy
or changing in an incorrect direction.
• ER84 Right height position sensor voltage range
less than 2.0VDC (1.5 VCD for flex platforms)
• ER85 Right height position sensor “lowered”
voltage greater than 2.5VDC.
• ER86 Right height position sensor “raised”
voltage less than 2.5VDC.
NOTE!
If any of these error codes
displays, t
he condition causing the error
must be correcte
d before the calibration
can be continued.
