9960 Self-Propelled Peanut Combine Electrical System
MAN091 06/03/05 151
Circuit Relays and Fuses
The power distribution boards in the central
electronics box and engine compartment
relay panel provide individual circuit
protection.
To clean:
1. Release latches.
2. Open the door and brush out any dust.
To replace a fuse or relay:
1. Turn off all switches.
2. Locate and replace the damaged
component.
Schematics and wiring codes are located in
the Appendices of this manual.
relays indicates an electrical problem
that must be identified and repaired.
