Appendices 9960 Self-Propelled Peanut Combine
A - 12 06/03/05 MAN091
Power Circuits
• Circuit numbers 0 – 99
• Red wires except as noted
Circuit Code Number Description
Wire Color
if not red
0 Negative Battery Cable Black
1 Positive Battery Cable Black
2 Alternator Output Lead Black
4 Start Relay Power
7 Ignition SW - "ACC" w/Diode protection
8 Ignition SW - "IGN" w/Diode protection
9 Ignition Power
10 Power Ground Black
11 Ignition Sw - "BATT"
12 Ignition Sw - "ACC"
13 Ignition Sw - "IGN"
14 Light Power
15 Engine Running Power
16 Control Power
17 A/C Power
8 Wiper Power
20 EMIP Power Ground Black
21 EMIP Power
22 Light Switch Power
23 Control Circuit Power
25 Service Power
26 Optional PDB Power
29 Service Light Power
31 359 Engine Throttle Control Power
32 Armrest Sensor Power
38 Auxillary Power Strip & Climatrak
39 Auxillary Power Strip Unswitched
40 ECU Ground Black
41 ECU Power
