Amadas 9960 - Propulsion Control Circuits; Separator Control Circuits

Appendices 9960 Self-Propelled Peanut Combine
A - 14 06/03/05 MAN091
Propulsion Control Circuits
• Circuit numbers 200 -299
• Light blue wires
Circuit Code Number Description
202 Four Wheel Drive Engage
206 Park Brake Sensor
Separator Control Circuits
• Circuit numbers 300 – 399
• Pink wires
Circuit Code Number John Deere Description Amadas Description
302 Separator Engage
305 Cylinder Speed Change
312 Threshing Clearance Increase Elevator Fan Dampener - open
313 Threshing Clearance Decrease Elevator Fan Dampener - close
314 Auger Swing In Sig Conveyor Swing In Sig
315 Auger Swing Out Sig Conveyor Swing Out Sig
316 Auger Swing In Conveyor Swing In
317 Auger Swing Out Conveyor Swing Out
319 Unoading Auger Engage Conveyor Engage
322 Walkers Plugged Peanut Door Open
326 Threshing Cleareance Increase Sig Elevator Fan Dampener Open Sig
327 Threshing Clearance Decrease Sig Elevator Fan Dampener Close Sig
348 Threshing Speed Change Sig
