9960 Self-Propelled Peanut Combine Appendices
MAN091 06/03/05 A - 19
Position Sensor Wires
• Circuit codes 800 – 849
• Tan wires
Circuit Code Number John Deere Description Amadas Description
800 RH Cornerpost Sensor Ground
801 Concave Clearance Sensor Power Elevator Fan Dampener Power
802 Concave Clearance Signal Elevator Fan Dampener Signal
804 Driver Position Sensor
812 Multifunction Handle Out of Neutral Sig
822 Multifunction Handle Position Signal
828 Feederhouse Position Signal
Visiontrak Wires
• Circuit codes 850 – 899
• Gray wires
Circuit Code Number Description
850 Visiontrak Ground
