Amadas 9960 - Rotary Screen Belt

Engine Service 9960 Self-Propelled Peanut Combine
142 06/03/05 MAN091
Rotary Screen Belt
Change the rotary screen belt as needed. To
change the belt:
1. Raise the idler and remove the rotary
screen drive belt.
2. Route the new belt according to the routing
sketch.
A – Rotary screen
B – Belt
C – Idlers
D – Drive sheave
Rotary screen drive belt
