Unloading Conveyor 9960 Self-Propelled Peanut Combine
202 06/03/05 MAN091
Before Using the Conveyor
A combine equipped with the Off-load
Conveying System (OCS) option comes
with an unloading conveyor. The conveyor
operates as follows:
• The conveyor is controlled from the
multi-function handle in the cab.
• Once the conveyor is started, there is a
five-second delay before the two augers
start delivering material to the conveyor.
The five-second delay is factory set, but
you can change the amount of delay
time as needed.
• Make sure there is a container
underneath the conveyor whenever it is
turned on. Running the conveyor
without a container will cause you to
dump product on the ground.
Conveyor Safety
It is important to remember the following
safety items when your combine is
equipped with the OCS option:
• Always keep in mind the length of the
conveyor and how far out it extends,
even when in the stored position.
• Be careful when backing the combine,
as the conveyor extends several feet
past the rear of the combine.
• When not using the conveyor, retract it
into its stowed position. Make sure the
conveyor is in place on the conveyor
rest.
• Always make sure the conveyor is in the
stowed position when you drive it on a
road.
• If necessary, the Quick Stop button on
the armrest panel can be used to stop
the conveyor immediately.
•
NEVER drive on roads with the
conveyor extended. Always make sure
the conveyor is in stowed position on
the conveyor rest before taking it on a
road.
• Be aware of th
when traveling. Even when in the
stored position, the conveyor extends
several feet past the
combine and presents a substantial
hazard for hitting obstructions.
•
Take particular care driving around
power lines. Hitt
cause significant shock or even death
for the combine operator.
•
NEVER stand or sit on the conveyor
when it is in motion.
•
NEVER stick your hand or any body
part into any moving part of the
conveyor.
