Rotary Screen
Rotary Screen Door
Opening the rotary screen door gives you
access to the rotary screen, oil cooler,
condenser, radiator, and charge air cooler.
To access these areas, pull the latch up and
pull the door open.
CAUTION
ALWAYS shut off the
engine and remove
the key when performing maintenance.
Rotary screen door
