Air Conditioner/Heater 9960 Self-Propelled Peanut Combine
180 06/03/05 MAN091
Evaporator Filter
Clean this filter only if servicing other filters
does not provide enough cooling. The
evaporator filter can be inspected from outside
the cab after the fresh air filter is removed. If it
looks clean, do not remove and clean it. If it
needs to be cleaned:
1. Remove 5 screws in the seat console.
2. Remove 6 screws and evaporator cover.
3. Remove two nuts and cap screws (A).
4. Remove controller (B).
5. Remove evaporator filter (C).
6. Clean as you would the other filters.
A – Cap Screws
B – Controller
C – Evaporator Filter
