9960 Self-Propelled Peanut Combine Hydraulic System
MAN091 06/03/05 173
Accumulator
The accumulator system is connected to the
header lift system between the lift cylinders
and solenoid control valve. It suspends the
header over uneven ground by compressing
nitrogen gas with a piston in the accumulator
tank.
Make sure the accumulator valve is wide open
(bottomed out counter-clockwise).
