9960 Self-Propelled Peanut Combine Appendices
MAN091 06/03/05 A - 13
Engine Control Circuits
• Circuit numbers 100 – 199
• White Wires
Circuit Code Number Description
104 Ignition Sw - "START" Sig
107 Ignition Sw - "START"
108 Start Safety Signal "Neutral Switched"
112 Starting Aid
119 Injector Pump Actuator ( - )
121 Analog Throttle
123 Inj Pump - Rack Position Sensor Reference
124 Inj Pump - Rack Position Sensor Sig
125 Inj Pump - Rack Position Sensor Ground
128 Inj Pump - Fuel Temp Sensor Sig
129 Inj Pump - Fuel Shutoff Sig
130 Inj Pump Sensor Ground
132 ECU Diagnostic / Serial Data Out
133 Fuel Flow Rate / Throttle Data out
134 Rack Position Voltage
138 Throttle Solenoid "A"
143 Tri-State Throttle Sig
144 Serial Input / Code Retention Clear
146 Code Retention Transmit
147 10% Throttle Reduction Signal (Wire is green)
148 10% Throttle Reduction 5V Power
